Digital Torque Wrench - Short Handle Type
Digital Torque Wrench - Short Handle Type Digital Torque Wrench - Short Handle Type Digital Torque Wrench - Short Handle Type Digital Torque Wrench - Short Handle Type
Digital Torque Wrench - Short Handle Type
Digital Torque Wrench - Short Handle Type
Digital Torque Wrench - Short Handle Type
Digital Torque Wrench - Short Handle Type

Digital Torque Wrench - Short Handle Type

ITEM NO: DT-030S2 / DT-085S3 / DT-135S4
Torque accuracy: CW ±2% & CCW ±3% tolerance of the set scale value
Operating mode: Peak hold mode (peak value detection) / Track mode (continuous display)
Torque unit selection: Nm, Ft-Lb, In-Lb, Kg-cm
Storage memory: 50 readings
Light indicator and buzzer are actatived when the preset torque is reached
Low battery indicator and auto shut off (after 5 minutes)
2 position, 48 teeth ratcheting mechanism: Forward / Reverse
Ergonomically designed bi-component soft grip handle
Tested and certified according to DIN EN ISO 6789, BS EN 26789, ASME B107.28

View More Details
Features
Torque Accuracy CW ± 2% / CCW ±3 %
Storage Memory 50 Readings
Torque Unit Selection Nm, Ft-Lb, In-Lb, Kg-cm
Display Resolution 0.01 Nm, 0.01 Ft-Lb, 0.1 In-Lb, 0.1 Kg-cm (DT-030S2)
0.1 Nm, 0.1 Ft-Lb, 1 In-Lb, 1 Kg-cm (DT-085S3, DT-135S4)
Operating Mode Peak Hold Mode / Track Mode
Gear Teeth 48Teeth
Ratcheting Mechanism Clockwise / Counterclockwise
Working Temperature -10°C ~ 60°C
Storage Temperature -20°C ~ 70°C
Humidity Up to 90% non-condensing
Battery 1.5V AAA x 2pcs
Battery Life 48 Hours
Auto Shut Off 5 Minutes (when not in use)

ITEM NO. DRIVE Torque Range L
(mm)		 CTN
(PCS)
(Nm) (Ft-Lb) (In-Lb) (Kg-cm)
DT-030S2 1/4" 1.5~30 1.11~22.12 13.3~265.5 15.3~306.1 221 12
DT-085S3 3/8" 4.2~85 3.1~62.7 37~752 43~867 271 12
DT-135S4 1/2" 6.8~135 5.0~99.5 60~1195 69~1378 380 6
● Accuracy guaranteed at 20% - 100% of full scale. (Maximum torque value)
