Digital Torque Wrench with Reversible Ratchet Insert Tool
Digital Torque Wrench with Reversible Ratchet Insert Tool Digital Torque Wrench with Reversible Ratchet Insert Tool Digital Torque Wrench with Reversible Ratchet Insert Tool
Digital Torque Wrench with Reversible Ratchet Insert Tool
Digital Torque Wrench with Reversible Ratchet Insert Tool
Digital Torque Wrench with Reversible Ratchet Insert Tool

Digital Torque Wrench with Reversible Ratchet Insert Tool

ITEM NO: DT-030I2 / DT-135I3 / DT-200I4 / DT-340I4
Torque Accuracy: CW ±2% & CCW ±3% tolerance of the set scale value
Operating mode: Peak hold mode (peak value detection) / Track mode (continuous display)
Torque Unit Selection: Nm, Ft-Lb, In-Lb, Kg-cm
Storage Memory: 50 Readings
12 way lights and buzzer when torque value is reached
Low battery indicator and auto shut off (after 5 minutes)
The ratchet is exchangeable, providing the option of using a 9x12 mm or 14x18 mm head size
2 Position, 52 Teeth Ratcheting Mechanism: Forward / Reverse
Ergonomically designed bi-component soft grip handle
Tested and certified according to DIN EN ISO 6789, BS EN 26789, ASME B107.28

View More Details
Features
Torque Accuracy CW ± 2% / CCW ±3 %
Storage Memory 50 Readings
Torque Unit Selection Nm, Ft-Lb, In-Lb, Kg-cm
Display Resolution 0.01 Nm, 0.01 Ft-Lb, 0.1 In-Lb, 0.1 Kg-cm (DT-030I2)
0.1 Nm, 0.1 Ft-Lb, 1 In-Lb, 1 Kg-cm (DT-135I3, DT-200I4, DT-340I4)
Operating Mode Peak Hold Mode / Track Mode
Head Size (W x H) 9 x 12mm - DT-030I2 & DT-135I3
14 x 18 mm - DT-200I4 & DT-340I4
Head Type Round Head Ratchet Insert
Gear Teeth 52 Teeth
Ratcheting Mechanism Clockwise / Counterclockwise
Working Temperature -10°C ~ 60°C
Storage Temperature -20°C ~ 70°C
Humidity Up to 90% non-condensing
Battery 1.5V AA x 2pcs
Battery Life 110 Hours
Auto Shut Off 5 Minutes (when not in use)

ITEM NO. HEAD SIZE

(mm)		 Torque Range Reversible
Ratchet		 L
(mm)		 CTN
(PCS)
(Nm) (Ft-Lb) (In-Lb) (Kg-cm)
DT-030I2 9x12 1.5~30 1.11~22.12 13.3~265.5 15.3~306.1 1/4" 390 6
DT-135I3 9x12 6.8~135 5.0~99.5 60~1195 69~1378 3/8" 410 6
DT-200I4 14x18 10~200 7.4~147.5 88~1770 102~2041 1/2" 520 6
DT-340I4 14x18 17~340 12.5~250.7 150~3009 173~3469 1/2" 640 6
● Accuracy guaranteed at 20% - 100% of full scale. (Maximum torque value)
